Can-Am Maverick X3 P-Drive Clutch Upgrade Combo (2017-2024 Turbo R / RR) | Pre-Calibrated

Best primary drive clutch for Can Am Maverick X3-R turbo 1000

SKU: 23431404

The complete drop-in cure for Can-Am Maverick X3 clutch creep, hard shifting at idle, and high-boost belt slip.

100% Pre-Assembled & Bolt-On: Brand-new primary and secondary clutch assemblies—no special assembly tools required.
Custom Calibrated: Pre-weighted and pre-sprung to your exact machine specs for optimal belt clamp and RPM response.
Cures Factory Sticking: Eliminates governor cup binding at idle to restore smooth, effortless shifting into gear.
Billet Performance: Matched secondary engineered to prevent belt glazing and heat fade on 32"+ or paddle tires.

Important: Please select your Tire Size, Horsepower, Elevation, and Riding Style below so our team can custom-calibrate your clutching prior to shipment.

Pricing: $1,499.95

Customize Your Item

Customers using tires that are +3" or larger than stock, should install this MCB HD secondary spring into the secondary clutch. This is for higher load situations (large tires do this by nature) and holds the belt better as well as holds initial upshift back slightly longer. This is also ideal for mud or high load type riding (rock crawling).

Add HD large tire sec spring

- Add HD large tire sec spring -

* required

For proper calibration of your clutch purchase we need to know the HP horsepower level of your Maverick

What HP level is your Maverick

- What HP level is your Maverick -

* required

This option gives you the option to add a puller that will remove your stock BRP clutch or the MCB clutch.

Add a clutch puller

- Add a clutch puller -

* required

This option is for adding a fail proof belt removal / install tool. This lightweight compact billet aluminum part simply threads into the female thread of the hollow shaft on all Maverick X3 and HD8/9 and 10 secondary clutches. Then you simple thread the side mounted bolt in and it securly opens up the secondary clutch for easy belt removal and install. Works on all X3 and HD8/9/10 models 2016-current regardless of the style secondary clutch you have on your machine (unless it's aftermarket)

Add Secondary Clutch Belt Openin

- Add Secondary Clutch Belt Openin -

* required

Add a Can Am X3 Secondary bolt and washer, Part number 420441990 / 420427243. These bolts are designed for one time use.

Bolt and Washer Kit

- Bolt and Washer Kit -

* required

This option allows you to choose between an OEM BRP secondary clutch or an MCB custom secondary with our exclusive "Tuff Wheel Rollers" and all billet helix.

OEM or MCB style secondary

- OEM or MCB style secondary -

* required

Want to add a Premium X3 Turbo drive belt that comes with a 3 year warranty? This belt is made by the same manufacturer as many OEM belts for all Powersports

Add Premium X3 Turbo drive belt

- Add Premium X3 Turbo drive belt -

* required

This option is for if you want to add a new Primary clutch bolt and washer for the new clutch.

Add a new bolt and washer

- Add a new bolt and washer -

* required

Larger tires apply more load and stress to the clutches. Large tires significantly reduce overall performance if not properly compensated for. MCB custom calibrates all clutches for tire size, elevation, and riding style. When you see +1-2" or +3-4" this means that your current tires are 1-2" or 3-4" taller than stock. So take a RZR 1000 for example. They typically come with 29" tires. If you have 32" tires, then that is a +3-4". Tire sizes that are +5-6 will INCLUDE the heavy duty secondary spring, This spring is needed to keep the belt from slipping with larger tires. (You Do Not need to select a HD Spring if offered in another Option).

Select your tire size

- Select your tire size -

* required

We need to know your elevation in order to calibrate your clutches properly. High elevation (thin air, less oxygen) robs horsepower from the motor and clutching needs to be adjusted for this accordingly.

Choose your elevation

- Choose your elevation -

* required

Please type out your year make and model * required

Qty:

Description
Details
Shipping
Reviews

Description

Pre-Calibrated & Ready to Bolt On: We do the math so you don't have to. Every combo is custom-weighted and sprung prior to shipment based on your exact tire size, terrain, elevation, and horsepower level.

1. Primary Drive Clutch Upgrades

Sticking-Resistant Assembly: Replaces factory governor cup wear points to ensure zero binding at idle and smooth gear engagement.
Reinforced Roller Guidance: High-grade composite rollers engineered to resist flat-spotting under extreme heat and heavy throttle cycles.
Precision Balanced: High-RPM dynamically balanced to eliminate vibration and extend crankshaft snout life.

2. Secondary Driven Clutch Upgrades

Machined Billet Helix Option: CNC-machined angles deliver aggressive belt bite without binding, preventing belt slip on 32"+ or paddle tires.
Optimized Sheave Angles: Engineered for superior belt grip and rapid backshifting when transitioning on and off throttle.
Severe-Duty Spring Rates: Matched to your riding profile to maintain optimal operating RPM in dunes, rock trails, or open desert.

3. Why Choose MCB Over OEM?

Complete Solution: Brand-new primary assembly and matched secondary assembly in one box.
Lower Belt Temperatures: Eliminates continuous micro-slip, drastically extending CVT belt life.
Direct Tech Support: Backed by real engine and powertrain specialists with decades of clutching experience.

Fitment & OEM Interchange Specifications

Detail	Specification
Compatible Models	Can-Am Maverick X3 / MAX (Turbo, Turbo R, Turbo RR, XMR, XRC, XDS, XRS, Smart-Shox)
Model Years	2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024
Replaces BRP OEM Part Numbers	420686870, 420280725, 420280687, 420280496, 420280495, 420686738 (and related supersessions)
Clutch Architecture	P-Drive Roller Primary Drive Pulley + Matched Secondary Driven Pulley
Assembly Status	100% Fully Assembled, Pre-Sprung, and Pre-Weighted (Drop-In Ready)

Details

SKU: 23431404
Item #: 23431404
Brand: Can Am
Condition: New

Shipping Information

Requires Shipping: Item Requires Shipping
Weight: 33.0 lbs.
Package Dimensions: W13.0000” x H18.0000” x L13.0000”
