Polaris RZR 925 / 1000 Turbo 2016-22 Primary drive clutch assembly, Razor MCB performance (TURBOS) 1323761 1323327 1323559

Best replacement upgrade primary drive clutch Polaris RZR turbo 925 1000

SKU: 23430953

2016-21 Polaris RZR 925 Turbo primary drive clutch assembly fully calibrated. Replaces = 1323761 1323327 1323559
Includes:
- 1 Fully assembled Primary drive clutch for your Polaris RZR925 Turbo, calibrated for 2 vs 4 seater, tire size, riding style, and elevation. (all prompts at checkout)

Pricing: $449.95

Customize Your Item

For proper calibration we need to know if your SxS is a 2-seater or 4-seater.

2 or 4 seater

- 2 or 4 seater -

* required

1 Primary clutch puller Polaris RZR Ranger 900/1000, Ranger 1000, General 1000, Turbo 925

Add a clutch puller

- Add a clutch puller -

* required

Complete bolt assembly for all Polaris RZR 1000's and various other models, see decription

Polaris clutch bolt 7518412 was

- Polaris clutch bolt 7518412 was -

* required

This option is to add a Spider to moveable sheave power puck. The stock RZR Turbo clutch uses sliding spider wedge blocks. The idea behind these are that they are self adjusting as they wear they just slide down further and at load (RPM) they are always tight between the two angles of the moveable sheave towers. This is a good design in general, however many Turbo customers complain of the "rattle" you get at idle. This is due to the fact that at idle there's not enough RPM or centrifugal force to slide the wedge blocks into position and take up the slack between the spider and moveable sheave towers. This is what causes the "rattle or knocking" at idle. Another potential down side to this design is that the sliding wedges are also somewhat self binding. The harder they load the moveable sheave the harder it is for them to let the sheave slide and close. Using these power pucks, these fill the gap and eliminate the sliding wedge blocks. They square up the spider to moveable sheave interface. With these inserts the surface area that is transferring the load from the spider to the moveable sheave is increased by 300% resulting in a smoother, less binding shift movement of the moveable sheave. These also in most cases eliminate the rattle at idle. When ordering these puck inserts they will be already installed by MCB when your clutch arrives.

Add Power Pucks

- Add Power Pucks -

* required

When adding larger tires or using in high load situations (sand or deep mud) it is very important to use a higher load secondary spring. This saves on belt wear, keeps the clutches cooler by reducing belt slippage. Recommended if your tire diameter is +3" or larger and or if you use it in the deep sand or mud. Not a bad idea for heavier 4-seaters as well especially if have extra weight with spare tires, coolers, nerf bars etc etc .

Add large tire high load sec spr

- Add large tire high load sec spr -

* required

High quality OEM equivalent drive belt. Manufactures 3-year warranty!! We use this brand belt on all our own high HP snowmobiles, SxS, and ATV's!!

Add Premium Belt

- Add Premium Belt -

* required

In order to calibrate your clutch properly give us your typical riding style.

Riding style

- Riding style -

* required

Larger tires apply more load and stress to the clutches. Large tires significantly reduce overall performance if not properly compensated for. MCB custom calibrates all clutches for tire size, elevation, and riding style. When you see +1-2" or +3-4" this means that your current tires are 1-2" or 3-4" taller than stock. So take a RZR 1000 for example. They typically come with 29" tires. If you have 32" tires, then that is a +3-4". Tire sizes that are +5-6 will INCLUDE the heavy duty secondary spring, This spring is needed to keep the belt from slipping with larger tires. (You Do Not need to select a HD Spring if offered in another Option).

Select your tire size

- Select your tire size -

* required

We need to know your elevation in order to calibrate your clutches properly. High elevation (thin air, less oxygen) robs horsepower from the motor and clutching needs to be adjusted for this accordingly.

Choose your elevation

- Choose your elevation -

* required

Qty:

Description
Details
Shipping
Documents
Reviews

Description

MCB Polaris RZR 925 primary drive clutch FOR ALL 2016-21 TURBO models.
- Uses the same belt as your original clutch
- Uses the same puller as your original clutch

If you are uncertain of your clutching issues and think you might also need a secondary clutch please look at our clutch combination kits that include both a Primary and a Secondary clutch, see SKU# 23431163

Comes fully calibrated ready to mount. Customized if you have oversize tires by choosing the appropriate box / tire size. We can also custom tune your clutch for specific applications. Rock crawling where high speed is not a need. Deep mud only where all you want is lots of low end torque. High speed trail of seasonal road running where you'll be in the mid to higher RPM's most the time. We can custom tune for your needs. Additional weights and spring rates are available for those need wide variation in adjustability.

This clutch is our own design. It is a replica of the OEM Polaris primary except our clutch uses superior bushing materials, special phenolic spider guides that can sustain significant more heat than OEM and provide the proper harness for maximum longevity. The faceplate is an all billet design that eliminates tower deflection, reducing binding and heat. The Billet face plate also allows for a larger bushing that is a self lubricating brass oil impregnated material. We use only the highest quality alloy materials for the sheaves and nitride coated tool steel on the main shaft and crankshaft mounting countersink area. The clutch is precision balanced. Add our Power Puck option for the ultimate in smoothness and durability.

We calibrate each clutch that leaves here for 2-seater vs 4-seater, Tire size, elevation, and riding preferences, etc. (see prompts at checkout)

Uses the same puller as your original clutch
