Arctic Cat driven secondary clutch, Team tied roller, splined, 2012-15 models, calibrated bolt on assembly.
Arctic Cat driven secondary clutch, Team tied roller, splined, 2012-15 models, calibrated assembly.
7251009
This is a complete secondary / driven clutch assembly for all Arctic Cat models 2012-15 with the splined jackshafts (see application chart in extended description). We build the clutch here prior to shipping for your exact year, make and model. We build it based on the information you will have to fill out at checkout (model, track length, elevation, modifications). There are several factors that determine which helix angle and spring rate to use for your model. It is important that you give us the proper data in order to calibrate your clutch properly.
MCB in conjunction with TEAM Industries is proud to announce the most advanced driven clutch in the snowmobile industry. The TEAM Tied Driven roller Clutch is an improvement from the TSS-04, and all OEM clutches that don' already come from the factory with a TEAM tied roller. Why?
- The moveable sheave opens axially to the stationary sheave without rotational movement. This translates to no scrubbing motion on the belt face producing less heat and friction.
- Being "tied" with two sets of rollers (internally and externally) along with wide, durable and spaced bushings this secondary does not "bind" upon the belt pulling on the sheaves, unlike all other designs in the industry.
- All torque is transmitted through the helix, making clutch tuning much more precise. This clutch was developed using the extensive testing and design resources.
- Instant Back Shift
- Improved Upshift
- Cooler operating temps / belt temps
- Increased Belt Life
- No Engine Reverse Clunk
- Unrivaled Torque Sensing
- Greater Efficiency Allows Lower Spring Rates
- Higher Top-End Speed Capability
- Rated and tested on sleds with as much as 320 HP!
- Used on all MCB shop and personal sleds where applicable.
- Exterior belt ride height adjustment
- Precision balanced
- Uses your same OEM belt application
- Complete with all new mounting hardware
- Alignment not necessary if your stock clutches are currently aligned.
- Alignment instructions and technical help available if necessary
- 1 year warranty
MCB in conjunction with TEAM Industries is proud to announce the most advanced driven clutch in the snowmobile industry. The TEAM Tied Driven roller Clutch is an improvement from the TSS-04, and all OEM clutches that don' already come from the factory with a TEAM tied roller. Why?
- The moveable sheave opens axially to the stationary sheave without rotational movement. This translates to no scrubbing motion on the belt face producing less heat and friction.
- Being "tied" with two sets of rollers (internally and externally) along with wide, durable and spaced bushings this secondary does not "bind" upon the belt pulling on the sheaves, unlike all other designs in the industry.
- All torque is transmitted through the helix, making clutch tuning much more precise. This clutch was developed using the extensive testing and design resources.
- Instant Back Shift
- Improved Upshift
- Cooler operating temps / belt temps
- Increased Belt Life
- No Engine Reverse Clunk
- Unrivaled Torque Sensing
- Greater Efficiency Allows Lower Spring Rates
- Higher Top-End Speed Capability
- Rated and tested on sleds with as much as 320 HP!
- Used on all MCB shop and personal sleds where applicable.
- Exterior belt ride height adjustment
- Precision balanced
- Uses your same OEM belt application
- Complete with all new mounting hardware
- Alignment not necessary if your stock clutches are currently aligned.
- Alignment instructions and technical help available if necessary
- 1 year warranty
Pricing:
$549.95
Description
Application:
- 6000 C-tec 2013-15 all options
- F 800 2012-15 all options
- 800 M 156 2012-15 all options
- 800 XF 141 2012-15 all options
- 800 XF 141 High country 2012-15 all options
- 1100 turbo 2012-15 all options
- 1100 Turbo with 240 HP tune 2012-15 all options
New Primary clutches available as well, and clutch combination packages available. MEaning MCB builds you a new Primary and Secondary clutch as a combination package.
- 6000 C-tec 2013-15 all options
- F 800 2012-15 all options
- 800 M 156 2012-15 all options
- 800 XF 141 2012-15 all options
- 800 XF 141 High country 2012-15 all options
- 1100 turbo 2012-15 all options
- 1100 Turbo with 240 HP tune 2012-15 all options
New Primary clutches available as well, and clutch combination packages available. MEaning MCB builds you a new Primary and Secondary clutch as a combination package.
Details
- 7251009
- 7251009
- TEAM
- New
Categories
Shipping Information
- Item Requires Shipping
- 12.0 lbs.
- W14.0000” x H14.0000” x L10.0000”
